Controller, 6-Way, Matter, Multi-white, Asynchronously, 3-Pin, 24 V
IC010.024.M.D.003
Control several light colors on one box
- JEDVER Connect Matter App(Thread technology)
- Detects and reports new nodes in the network independently
- Intuitively assign functions to switches
- Set up light groups and scenes
- The JEDVER connect matter App is free for Apple iOS® and Android™
- Work with matter voice control smart spearker
| Low voltage plug |
3-pin 24 V |
| Input ports |
1 x plug, 2-pin 24 V |
| Connected output ports | 6 x sockets, 3-pin 24 V |
| Control input ports | BLE 5.0, Sensor switch+ Matter approved control unit |
| Power rating |
Max 200 W depends the out wattage of LED driver |
| Voltage | 24.00 V |
| Color system | Multi-white |
| Area of application | For on/off switching and dimming (0–100 %) of multi-white lights |
| Suitable for | For multi-white lights |
| Version | Asynchronously |
| Color/finish |
Black |
| Dim. (L x W x H) |
75 x 50 x 15 mm |
| Installation |
Plugged directly to driver |
| Distance between controls max. |
30.00 m |
| Standby power consumption |
0.25 W |
| Scope of delivery |
1 control unit |
| Switching function |
Programmable with app or Jedver sensor switches |
Important info
- Control unit defines the application(incl. colour system) and functions of smart-drivers.
- The specified power rating is the maximum capacity.
- The actual power rating depends on the connected driver.
- Switches to control unit: 6 m.
- Control unit in Thread mesh: 10-30 m.
5.0
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
POWER SUPPLY
Control unit
| Output power | Power rating | Current carrying capacity | Standby power consumption | Dimensions (L x W x H) | Connected output ports |
Control type |
Article number | |
| W | A (per port) | W | mm | |||||
| IC005 | max. 200 | 10.0 | 0.25 | 75 x 50 x 15 | 6 x socket 2-pin 24 V, 10 A | synchronous | IC005.024.M.B.003 | |
| IC006 | 5+1 x socket 2-pin 24 V, 10 A | asynchronous | IC006.024.M.D.003 | |||||
| IC007 | max. 200 | 10.0 | 0.25 | 75 x 50 x 15 | 6 x socket 2-pin 24 V, 10 A | synchronous | IC007.024.M.B.003 | |
| IC009 | asynchronous | IC009.024.M.D.003 | ||||||
| IC008 | max. 200 | 5.0 | 0.25 | 75 x 50 x 15 | 6 x socket 3-pin 24 V, 10 A | synchronous | IC008.024.M.B.003 | |
| IC0010 | asynchronous | IC010.024.M.D.003 | ||||||
| IC0011 | max. 200 | 5.0 | 0.25 | 75 x 50 x 15 | 6 x socket 4-pin 24 V, 5 A | synchronous | IC011.024.M.B.003 | |
| IC0012 | max. 200 | 5.0 | 0.25 | 75 x 50 x 15 | 4 x socket 6-pin 24 V, 5A | synchronous | IC012.024.M .B.003 |
Documentation
Product ManualMore Information
Product features
- MATTER READY
- BLUETOOTH READY
matter-certified and therefore compatible with all matter-enabled devices, including
brands such as Google Home, Apple HomeKit and Amazon Alexa that support matter
